Flexible Strip Brush Aluminum Diagram - Metric Version

SEALEZE® Standard Flexible Strip Brush
Section
Section
Product Code
Nylon
Standard
Filament
Diameter
Dimensions
See Note*
OAT
±0.38
Standard Continuous
Length (feet)
XY
C FXC106BL 0.15 4.572 5.080 22.10 30.48
C FXC110BL 0.15 4.572 5.080 32.51 30.48
D FXD109BL 0.20 5.842 6.223 31.75 30.48
D FXD112BL 0.20 5.842 6.223 38.10 30.48
D FXD116BL 0.30 5.842 6.223 48.77 30.48
D FXD120BL 0.30 5.842 6.223 58.67 30.48
D FXD130BL 0.30 5.842 6.223 84.07 30.48

* Tolerence for C & D sections, ± 0.508 inches.

Ez-Flez strip brush will fit in SEALEZE® aluminum holders. Visit the aluminum holders page for more information.


SEALEZE® Standard Flexible Strip Brush with Integrated Holder †
Section
Section
Product Code
Nylon
Standard
Filament
Diameter
Dimensions
See Note*
Flange
Thickness
±0.508
Flange
Height
±1.27
Exposed†
±0.38
Standard Continuous
Length (feet)
XY
C FXC80IH06BL 0.15 4.57 4.83 1.52 12.70 15.75 3.05
C FXC80IH10BL 0.15 4.57 4.83 1.52 12.70 26.16 3.05
D FXD80IH09BL 0.20 5.59 6.35 1.52 13.97 23.62 3.05
D FXD80IH12BL 0.20 5.59 6.35 1.52 13.97 29.97 3.05
D FXD80IH16BL 0.30 5.59 6.35 1.52 13.97 40.64 3.05
D FXD80IH20BL 0.30 5.59 6.35 1.52 13.97 50.55 3.05
D FXD80IH30BL 0.30 5.59 6.35 1.52 13.97 75.95 3.05

* Tolerence for C & D sections, ±0.508 inches.
† Exposed filament from bottom of integrated holder (filament length)

*For integrated holders, exposed length equals filament length.


Stock Holders for SEALEZE® Flexible Strip Brush
Fits Brush Section SizeHolder Product CodeXBCD
 mmmmmm
Straight Flanges
C XTC380CLA 180° 11.151 7.899 7.417
C XTC381CLA 180° 19.050 7.899 7.417
C XTC382CLA 180° 38.100 7.899 7.417
C XTC383CLA 180° 76.200 7.899 7.417
D (1) XTD480CLA 180° 18.059 9.931 9.297
D XTD482CLA 180° 38.100 9.931 9.297
D XTD483CLA 180° 76.200 9.931 9.297
Angled Flanges
C XTC345CLA 45° 31.750 7.899 7.417
D XTD445CLA 45° 21.438 9.931 9.296
D XTD45XCLA 45° 48.006 9.931 9.296
D (3) XTD45RCLA 45° 25.400 9.931 9.296
Right-Angled Flanges
C XTC390CLA 90° 16.840 7.696 8.407
D XTD490CLA 90° 17.704 9.271 9.931

(1)Also available in roll-formed stainless steel,
(3) Reverse flange
